Diffusion Bonded Powder
Diffusion bonded powder grades are designed for applications requiring controlled alloying elements, stable alloy distribution, compressibility and processing consistency.
Diffusion Bonded Powder for Stable Alloy Distribution
Diffusion bonded powder products are designed for applications requiring stable alloy distribution, controlled chemical composition and reliable processing performance.
Different grades can be reviewed according to customer application, alloying element requirements, compressibility, green density and target performance.
Typical Diffusion Bonded Powder Grades
Typical diffusion bonded powder grades can be reviewed according to chemical analysis, physical properties and processing requirements.
Powder Metallurgy & Industrial Applications
PM-100.29D1
A diffusion bonded powder grade containing nickel, molybdenum and copper for applications requiring stable chemical and physical performance.
Key Data:
Ni: 1.73 wt%
Mo: 0.52 wt%
Cu: 1.58 wt%
Apparent Density: 3.05 g/cm³
PM-100.29D2
A diffusion bonded powder grade with higher nickel content and controlled molybdenum and copper additions for customer-specific applications.
Key Data:
Ni: 3.82 wt%
Mo: 0.53 wt%
Cu: 1.36 wt%
Flow Rate: 26 s/50 g
PM-100.29D3
A nickel-molybdenum alloyed powder grade with controlled particle size distribution and physical properties for industrial applications.
Key Data:
Ni: 3.83 wt%
Mo: 1.37 wt%
Cu: 2.00 wt%
Green Density @ 600 MPa: 7.13 g/cm³
PM-100.29D4
A diffusion bonded powder grade with controlled nickel, molybdenum and copper content for applications requiring reliable processing consistency.
Key Data:
Ni: 1.51 wt%
Mo: 0.51 wt%
Cu: 1.85 wt%
Apparent Density: 3.03 g/cm³
PM-100.29D5
A nickel-molybdenum alloyed powder grade with controlled particle size distribution and physical properties for industrial applications.
Key Data:
Ni: 1.085 wt%
Mo: 1.493 wt%
Cu: 1.145 wt%
Flow Rate: 26.1 s/50 g
Custom Alloy Composition
Grades can be reviewed according to customer formulation, alloying elements and target performance requirements.
General TDS documents are available for typical diffusion bonded powder grades according to customer requirements.
Need Diffusion Bonded Powder for Your Application?
Send us your application, target specification, current supplier grade or required alloy composition. Our team will review your requirements and recommend a suitable powder option.
